Digital DC Ammeter – 0-100DCA 12/24 Volts System

• Monitor marine/land based power distribution & generating systems (ABYC E-11.9.3.2.)
• AC voltmeter and AC ammeter are true RMS (ABYC E-11.9.3.2.)
• Surface mount with only two 5/32″ diameter holes
• Window mount in standard 2.5″ analog meter cutout (2.90″ W X 1.28″ H)
• Three digit LED display (Frequency meters are two digits)
• Reversed Polarity Protected
• Splashproof front
• Includes pigtails, mounting hardware, & instructions

Specifications:

• Display Character Size: 9/16″
• Input Voltage: 8-32VDC
• Power Consumption: 1Watt 12/24VDC
• Accuracy: +/- 1 Count
• Operating Temperature Range: 32-122 deg. F
• Dimensions: 3.08″W, 2.38″H, 1.0″D

Manufacturer Part Number: 570-002
