Paneltronics Breaker 50 Amps A-Frame Magnetic Waterproof

Paneltronics Breaker 50 Amps A-Frame Magnetic Waterproof

Panel Seal / Waterproof “A” Frame Magnetic Circuit Breakers

• Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
• Meets all American Boat and Yacht Council (ABYC) Standards for non ignition protected circuit breakers
• UL Recognized (UL 1077) for use in the U.S.A., and CSA Certified for use in Canada
• Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
• Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)

Specifications

• Handle Color: Metal with Silicon rubber seal
• Maximum Amperage: 50 Amps
• Maximum Voltage /AIC: 32 VDC/ 2,500 Amps with no Back-up Fuse (ABYC E-11.10.1.5.5)
• Rated Switch Cycles: Rated Switch Cycles 10,000 actuations at rated current and voltage
• Electrical Hardware: Screw 10-32 x 3/8″ pan combo head (P/N 197-188)
• Mounting Hardware: Hex nut 1/2-32 (supplied with circuit breaker), Lockwasher 1/2″ internal tooth (supplied with circuit breaker)
• Optional Boot: Black silicone rubber (P/N 048-015)

  Manufacturer Part Number: 206-058S
