Newmar 12-24-25 Step Up Dc-Dc Converter 25 Amp Continuous

Newmar 12-24-25 Step Up Dc-Dc Converter 25 Amp Conitnuos

These “UP” converters produce 24 volts from 12 volt systems and are ideal for managing dual voltage applications on marine vessels without having to install a 24 volt battery and dedicated charging system. Choose from two types depending on your application:

In the Standard, Non-Isolated Series the 12V input and 24V output share a common negative ground and are ideal when installing certain electronics that operate better on 24 volts when a robust 12 volt system exists. Models available in outputs of 7, 16 and 25 amps.

Standard, Non-Isolated Series

• Intended for use on negative ground systems
• 10 -15 VDC input range
• Available in 7, 16 and 25 amp outputs
• Current limited, voltage spike suppression, automatic thermal shutdown and recovery

Model	Input voltage	Output voltage	Output Amps Intermittent	Output Amps Continuous	Case Size	Weight
						Lbs	Kg
Standard – Non-Isolated
12-24-7	10-15	27.2	7	7	C-1	1.4	.64
12-24-16	10-15	27.2	16	16	C-2	3.55	1.61
12-24-25	10-15	27.2	25	25	C-3	4.1	1.86

Case Size

Case	Inches			Centimeters
	H	W	D	H	W	D
C-1	3.5	3.5	1.75	8.9	8.9	4.5
C-2	4.25	5.9	14.0	10.8	15.0	35.6
C-3	6.0	6.8	16.5	15.2	17.3	41.9

Specifications

Input: 10 – 15V DC

Output: 27.2 VDC +/-5% at extreme temperature load, input, tolerance, etc.

Ripple: <100mV P-P

Regulation: +/- 5% Line/Load

Duty Cycle:
Intermittent: 2 minutes, 20% duty
Continuous: 24 hours, 100% duty

Operating Temp: -25˚ – 30˚ C, derate linearly from 30 to 0% @ 80˚ C

Mechanical

• Efficiency: 93% – Typical.
• Anodized aluminum, glass filled polycarbonate, dust water and impact resistance to IP533
• Front panel terminal block
• Output indicator: Green LED

Manufacturer Part Number: 12-24-25
