Maretron 0-500 Psi Transducer
$156.89
| Special Shipping Message | Free Ground Shipping* |
|---|---|
| Manufacturer Part Number: | PT-0-500PSI-01 |
Maretron 0-500 Psi Transducer
Pressure Transducer Mechanical Drawing
|
Pressure Transducer Specifications Part Number |
Range |
Accuracy |
Type |
|
PT-0-3PSI-01 |
0 to 3 PSI (0.21 bar) |
± 2% Full Scale |
Gauge |
|
PT-0-5PSI-01 |
0 to 5 PSI (0.34 bar) |
± 2% Full Scale |
Gauge |
|
PT-0-10PSI-01 |
0 to 10 PSI (0.69 bar) |
± 2% Full Scale |
Gauge |
|
PT-0-50PSI-01 |
0 to 50 PSI (3.45 bar) |
± 1% Full Scale |
Gauge |
|
PT-0-100PSI-01 |
0 to 100 PSI (6.89 bar) |
± 0.5% Full Scale |
Gauge |
|
PT-0-500PSI-01 |
0 to 500 PSI (34.47 bar) |
± 0.5% Full Scale |
Absolute |
|
PT-0-3000PSI-01 |
0 to 3000 PSI (206.84 bar) |
± 0.5% Full Scale |
Absolute |
|
Specification |
Value |
|
Operating Temperature |
-40°C to 105°C |
|
Storage Temperature |
-40°C to 105°C |
|
Proof Pressure |
2.4 × Full Scale |
|
Burst Pressure |
2.4 × Full Scale |
|
Reverse Voltage Protection |
± 16V over 5 Minutes |
|
Construction |
304L stainless steel |
|
Pressure/Temperature Cycles |
0 to FS @ 8Hz; and ?40°C to 105°C for > 1.8×106 cycles |
|
Thermal Shock |
105°C to ?40°C, 0.5 hr soaks at Temp. (2s Transfer) for 300 cycles |
|
Vibration |
100 to 2000 Hz, 20g Sinusoidal, 3 Axes for 144 hours |
|
EMC Compatibility |
10 Volts/meter per EN 61000-4-3 |
|
Humidity |
85°C and 90% to 95% R. H. for 250 hours |
|
Weight |
85g |
Manufacturer Part Number: PT-0-500PSI-01
