Windlass Thermal Circuit Breaker Panel – 70Amp

Panel mounted, a waterproof breaker that works with DC systems up to 48 volts.  This trip-free breaker is ideal for a windlass circuit.

Features:

• Works with DC systems up to 48 volts
• Clear, single lever operation
• Combines switching and circuit protection into a single device
• “Trip Free” design cannot be held “ON” during fault current condition
• Ignition protected

Technical Specifications:

• Circuit Breaker Class – Type III
• Circuit Breaker Type – Thermally responsive bi-metal blade
• Maximum Voltage – 48V DC
• Amperage – 70Amp
• Mounting – Panel Mount
• Weight: -.5lb (0.23 kg)

*Sold as an Individual

Manufacturer Part Number: 68000240
